LD17

LHD LD17

LHD LD17
Technical Specifications PDF

Ask for the product

Technical specification

  • Length:

  • 11 500 mm

  • Width:

  • 3 380 mm

  • Height:

  • 2 350 mm

  • Total weight:

  • 48 600 kg

  • Standard bucket:

  • 8,6 m3

  • Tramming capacity:

  • 172 kN

  • Power rating:

  • 330 kW

  • Driving speed:

  • –

  • 1st gear

  • 5,0 km/h

  • 2nd gear

  • 9,0 km/h

  • 3rd gear

  • 15,0 km/h

  • 4th gear

  • 20,0 km/h
